Electric technology, four core attributes to create greater value for customers
Yutong D-power ultra-integrated electric driving chain
Motor torque sensitivity increase by 4 times, instantaneous burst increase by 80%
Main winch output power 30% higher than fuel type piling rig
Yutong D-power ultra-integrated electric driving chain
Extended range mode saves 40%-50% fuel cost
Main winch energy recovery rate can reach 50%
Energy utilization efficiency of pure electric piling rig can reach 87%, which is more than 62% higher than that of fuel type piling rig
Yutong D-power ultra-integrated electric driving chain
Real-time monitoring to parts, early warning accuracy ≥90%
Machine condition can be checked anywhere through mobile APP
Yutong ReCtrl technology won the Second Prize of 2015 National Science and Technology Progress Award
Yutong electric piling rig has a cumulative working time of more than 80,000 hours
Three-Electric System (battery, electric motor, electric control) warranty is 5 years /10000 hours
Technical Specifications
-
YTR306HE
-
YTR266HE
-
YTR236HES
-
-
Lifting capacity（kN)330
-
Max.drilling diameter（mm）2,500
-
Max.depth（m）51/94,65/100(special)
-
Range extender typeB6.7CS4 290C
-
Range extender power（kW）214
-
Max.output torque （kN·m）320
-
Crowd force（kN)275
-
Lifting capacity（kN)280
-
Max.drilling diameter（mm）2,200
-
Max.depth（m）58/73/87
-
Range extender typeQSB5.9 CS4
-
Range extender power（kW）154
-
Max.output torque （kN·m）266
-
Crowd force（kN)230
-
Lifting capacity（kN)240
-
Max.drilling diameter（mm）2,000
-
Max.depth（m）54/68
-
Range extender typeQSB5.9 CS4
-
Range extender power（kW）154
-
Max.output torque （kN·m）246
-
Crowd force（kN)230
-
Make The Switch With Yutong
Access reliable and efficient transportation options with Yutong, enabling your business to embrace sustainability and secure a greener, more enduring future
